Cyclone 55

Passive dual 5" two-way surface mount loudspeaker


Key Features

  • Compact fibreglass enclosure
  • Non-resonant structure
  • Wide dipersion pattern
  • Marine-grade stainless steel fittings
  • UV-resilient paint
  • Custom colours available
  • Applications:Cruise Ships,Outdoor,Bar, Club, Lounge,Hotel, Restaurant.

OverView

The Cyclone 55 offers high levels of fidelity and definition from an ultra-compact and visually appealing format, in a weather-protected package that is ideally suited to coastal outdoor applications ranging from beach bars, resorts and cruise ships, to hotels and public spaces. With a dedicated bracket, the Cyclone 55 can be installed quickly and securely, and its wide range of adjustment allows the loudspeaker’s wide dispersion pattern to be accurately aimed at large audience areas using the least number of loudspeakers.

Specifications

  • Frequency Response:70 Hz - 23 kHz ±3 dB
  • Efficiency:92 dB 1w/ 1m
  • Crossover Point: 3.6 kHz passive
  • Impedance: 16 ohms
  • Power Handling :120 Watts AES
  • Maximum Output :110 dB cont, 114 dB peak
  • Driver Configuration :2 x 5" LF, 2 x 1" soft dome HF tweeters
  • Dispersion :110°H x 70°V
  • Connectors: Phoenix Connectors with link out
  • Height :192 mm (7.6")
  • Width: 309 mm (12.2")
  • Depth: 207 mm (8.1")
  • Weight: 3.2 kg (7.1 lbs)
  • Enclosure :Fibreglass
  • Rigging :Included Easy Hang wall bracket
  • Finish: Smooth cellulose
